16.5.1.37 IRQFRAMETHOLDRX10 Register (offset = 230h) [reset = 0h]
IRQFRAMETHOLDRX10 is shown in Figure 16-58 and described in Table 16-66.
Figure 16-58. IRQFRAMETHOLDRX10 Register
31 30 29 28 27 26 25 24
FRAME_THRES_RX1_3
R/W-0h
23 22 21 20 19 18 17 16
FRAME_THRES_RX1_2
R/W-0h
15 14 13 12 11 10 9 8
FRAME_THRES_RX1_1
R/W-0h
7 6 5 4 3 2 1 0
Reserved
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-66. IRQFRAMETHOLDRX10 Register Field Descriptions
Bit Field Type Reset Description
31-24 FRAME_THRES_RX1_3 R/W 0h FRAME threshold value for rx_pkt_cmp_0 for USB1 Endpoint 3.
23-16 FRAME_THRES_RX1_2 R/W 0h FRAME threshold value for rx_pkt_cmp_0 for USB1 Endpoint 2.
15-8 FRAME_THRES_RX1_1 R/W 0h FRAME threshold value for rx_pkt_cmp_0 for USB1 Endpoint 1.
1798
Universal Serial Bus (USB) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
