Introduction
21.1 Introduction
The multi-master I2C peripheral provides an interface between a CPU and any I2C-bus-compatible device
that connects via the I2C serial bus. External components attached to the I2C bus can serially
transmit/receive up to 8-bit data to/from the CPU device through the two-wire I2C interface.
The I2C bus is a multi-master bus. The I2C controller does support the multi-master mode that allows
more than one device capable of controlling the bus to be connected to it. Each I2C device is recognized
by a unique address and can operate as either transmitter or receiver, according to the function of the
device. In addition to being a transmitter or receiver, a device connected to the I2C bus can also be
considered as master or slave when performing data transfers. Note that a master device is the device
which initiates a data transfer on the bus and generates the clock signals to permit that transfer. During
this transfer, any device addressed by this master is considered a slave.
21.1.1 I2C Features
The general features of the I2C controller are:
• Compliant with Philips I2C specification version 2.1
• Supports OmniVision Serial Camera Control Bus Protocol (SCCB)
• Supports standard mode (up to 100K bits/s) and fast mode (up to 400K bits/s).
• Multimaster transmitter/slave receiver mode
• Multimaster receiver/slave transmitter mode
• Combined master transmit/receive and receive/transmit modes
• 7-bit and 10-bit device addressing modes
• Built-in 32-byte FIFO for buffered read or writes in each module
• Programmable clock generation
• Two DMA channels, one interrupt line
21.1.2 Unsupported I2C Features
The I2C module features not supported in this device are shown in Table 21-1.
Table 21-1. Unsupported I2C Features
Feature Reason
SCCB Protocol SCCB signal not pinned out
High Speed (3.4 MBPS) operation Not supported
