USB Registers
www.ti.com
16.5.7.112 QUEUE_19_B Register (offset = 2134h) [reset = 0h]
QUEUE_19_B is shown in Figure 16-388 and described in Table 16-402.
Figure 16-388. QUEUE_19_B Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved QUEUE_BYTE_COUNT
R-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-402. QUEUE_19_B Register Field Descriptions
Bit Field Type Reset Description
27-0 QUEUE_BYTE_COUNT R-0 0 This field indicates how many bytes total are contained in all of the
packets which are currently queued on this queue.
2220
Universal Serial Bus (USB) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
