15.2.4.4.1 Dead-Band Generator Control Register (DBCTL)
The dead-band generator control register (DBCTL) is shown in Figure 15-82 and described in Table 15-
75.
Figure 15-82. Dead-Band Generator Control Register (DBCTL)
15 6 5 4 3 2 1 0
Reserved IN_MODE POLSEL OUT_MODE
R-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 15-75. Dead-Band Generator Control Register (DBCTL) Field Descriptions
Bits Name Value Description
15-6 Reserved 0 Reserved
5-4 IN_MODE 0-3h Dead Band Input Mode Control. Bit 5 controls the S5 switch and bit 4 controls the S4 switch shown in
Figure 15-34. This allows you to select the input source to the falling-edge and rising-edge delay.
To produce classical dead-band waveforms, the default is EPWMxA In is the source for both falling and
rising-edge delays.
0 EPWMxA In (from the action-qualifier) is the source for both falling-edge and rising-edge delay.
1h EPWMxB In (from the action-qualifier) is the source for rising-edge delayed signal.
EPWMxA In (from the action-qualifier) is the source for falling-edge delayed signal.
2h EPWMxA In (from the action-qualifier) is the source for rising-edge delayed signal.
EPWMxB In (from the action-qualifier) is the source for falling-edge delayed signal.
3h EPWMxB In (from the action-qualifier) is the source for both rising-edge delay and falling-edge delayed
signal.
3-2 POLSEL 0-3h Polarity Select Control. Bit 3 controls the S3 switch and bit 2 controls the S2 switch shown in Figure 15-
34. This allows you to selectively invert one of the delayed signals before it is sent out of the dead-band
submodule.
The following descriptions correspond to classical upper/lower switch control as found in one leg of a
digital motor control inverter.
These assume that DBCTL[OUT_MODE] = 1,1 and DBCTL[IN_MODE] = 0,0. Other enhanced modes
are also possible, but not regarded as typical usage modes.
0 Active high (AH) mode. Neither EPWMxA nor EPWMxB is inverted (default).
1h Active low complementary (ALC) mode. EPWMxA is inverted.
2h Active high complementary (AHC). EPWMxB is inverted.
3h Active low (AL) mode. Both EPWMxA and EPWMxB are inverted.
1-0 OUT_MODE 0-3h Dead-band Output Mode Control. Bit 1 controls the S1 switch and bit 0 controls the S0 switch shown in
Figure 15-34. This allows you to selectively enable or bypass the dead-band generation for the falling-
edge and rising-edge delay.
0 Dead-band generation is bypassed for both output signals. In this mode, both the EPWMxA and
EPWMxB output signals from the action-qualifier are passed directly to the PWM-chopper submodule.
In this mode, the POLSEL and IN_MODE bits have no effect.
1h Disable rising-edge delay. The EPWMxA signal from the action-qualifier is passed straight through to
the EPWMxA input of the PWM-chopper submodule.
The falling-edge delayed signal is seen on output EPWMxB. The input signal for the delay is determined
by DBCTL[IN_MODE].
2h Disable falling-edge delay. The EPWMxB signal from the action-qualifier is passed straight through to
the EPWMxB input of the PWM-chopper submodule.
The rising-edge delayed signal is seen on output EPWMxA. The input signal for the delay is determined
by DBCTL[IN_MODE].
3h Dead-band is fully enabled for both rising-edge delay on output EPWMxA and falling-edge delay on
output EPWMxB. The input signal for the delay is determined by DBCTL[IN_MODE].
