McASP Registers
www.ti.com
22.4.1.13 Receiver Global Control Register (RGBLCTL)
Alias of the global control register (GBLCTL). Writing to the receiver global control register (RGBLCTL)
affects only the receive bits of GBLCTL (bits 4-0). Reads from RGBLCTL return the value of GBLCTL.
RGBLCTL allows the receiver to be reset independently from the transmitter. The RGBLCTL is shown in
Figure 22-51 and described in Table 22-24. See Section 22.4.1.9 for a detailed description of GBLCTL.
Figure 22-51. Receiver Global Control Register (RGBLCTL)
31 16
Reserved
R-0
15 13 12 11 10 9 8
Reserved XFRST XSMRST XSRCLR XHCLKRST XCLKRST
R-0 R-0 R-0 R-0 R-0 R-0
7 5 4 3 2 1 0
Reserved RFRST RSMRST RSRCLR RHCLKRST RCLKRST
R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 22-24. Receiver Global Control Register (RGBLCTL) Field Descriptions
Bit Field Value Description
31-13 Reserved 0 Reserved. The reserved bit location always returns the default value. A value written to this field has no
effect. If writing to this field, always write the default value for future device compatibility.
12 XFRST x Transmit frame sync generator reset enable bit. A read of this bit returns the XFRST bit value of
GBLCTL. Writes have no effect.
11 XSMRST x Transmit state machine reset enable bit. A read of this bit returns the XSMRST bit value of GBLCTL.
Writes have no effect.
10 XSRCLR x Transmit serializer clear enable bit. A read of this bit returns the XSRCLR bit value of GBLCTL. Writes
have no effect.
9 XHCLKRST x Transmit high-frequency clock divider reset enable bit. A read of this bit returns the XHCLKRST bit
value of GBLCTL. Writes have no effect.
8 XCLKRST x Transmit clock divider reset enable bit. A read of this bit returns the XCLKRST bit value of GBLCTL.
Writes have no effect.
7-5 Reserved 0 Reserved. The reserved bit location always returns the default value. A value written to this field has no
effect. If writing to this field, always write the default value for future device compatibility.
4 RFRST Receive frame sync generator reset enable bit. A write to this bit affects the RFRST bit of GBLCTL.
0 Receive frame sync generator is reset.
1 Receive frame sync generator is active.
3 RSMRST Receive state machine reset enable bit. A write to this bit affects the RSMRST bit of GBLCTL.
0 Receive state machine is held in reset.
1 Receive state machine is released from reset.
2 RSRCLR Receive serializer clear enable bit. A write to this bit affects the RSRCLR bit of GBLCTL.
0 Receive serializers are cleared.
1 Receive serializers are active.
1 RHCLKRST Receive high-frequency clock divider reset enable bit. A write to this bit affects the RHCLKRST bit of
GBLCTL.
0 Receive high-frequency clock divider is held in reset and passes through its input as divide-by-1.
1 Receive high-frequency clock divider is running.
0 RCLKRST Receive clock divider reset enable bit. A write to this bit affects the RCLKRST bit of GBLCTL.
0 Receive clock divider is held in reset.
1 Receive clock divider is running.
3848
Multichannel Audio Serial Port (McASP) SPRUH73H–October 2011–Revised April 2013
