USB Registers
www.ti.com
16.5.1.31 IRQFRAMETHOLDRX02 Register (offset = 218h) [reset = 0h]
IRQFRAMETHOLDRX02 is shown in Figure 16-52 and described in Table 16-60.
Figure 16-52. IRQFRAMETHOLDRX02 Register
31 30 29 28 27 26 25 24
FRAME_THRES_RX1_11
R/W-0h
23 22 21 20 19 18 17 16
FRAME_THRES_RX1_10
R/W-0h
15 14 13 12 11 10 9 8
FRAME_THRES_RX1_9
R/W-0h
7 6 5 4 3 2 1 0
FRAME_THRES_RX1_8
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-60. IRQFRAMETHOLDRX02 Register Field Descriptions
Bit Field Type Reset Description
31-24 FRAME_THRES_RX1_11 R/W 0h FRAME threshold value for rx_pkt_cmp_0 for USB0 Endpoint 11.
23-16 FRAME_THRES_RX1_10 R/W 0h FRAME threshold value for rx_pkt_cmp_0 for USB0 Endpoint 10.
15-8 FRAME_THRES_RX1_9 R/W 0h FRAME threshold value for rx_pkt_cmp_0 for USB0 Endpoint 9.
7-0 FRAME_THRES_RX1_8 R/W 0h FRAME threshold value for rx_pkt_cmp_0 for USB0 Endpoint 8.
USBSS IRQ_FRAME_THRSHOLD_RX0_2 Register
1792
Universal Serial Bus (USB) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
