24.2.1 McSPI Connectivity Attributes
The general connectivity attributes for the McSPI module are shown in Table 24-2.
Table 24-2. McSPI Connectivity Attributes
Attributes Type
Power Domain Peripheral Domain
Clock Domain
PD_PER_L4LS_GCLK (Interface/OCP)
PD_PER_SPI_GCLK (Func)
Reset Signals PER_DOM_RST_N
Idle/Wakeup Signals Smart Idle
Interrupt Requests
1 interrupt to MPU subsystem and PRU-ICSS (McSPI0INT)
1 interrupt to MPU subsystem only (McSPI1INT)
DMA Requests
4 DMA requests per instance to EDMA
• 1 RX request for CS0 (SPIREVT0)
• 1 TX request for CS0 (SPIXEVT0)
• 1 RX request for CS1 (SPIREVT1)
• 1 TX request for CS1 (SPIXEVT1)
Physical Address L4 Peripheral slave port
24.2.2 McSPI Clock and Reset Management
The SPI module clocks can be woken up in two manners: by the SPI module itself using the SWAKEUP
signal (refer to the module functional spec for detailed conditions), or directly from an external SPI master
device by detecting an active low level on its chip select input pin (CS0n) using a GPIO attached to that
device pin. Neither of these methods is supported on the device.
Table 24-3. McSPI Clock Signals
Clock Signal Max Freq Reference / Source Comments
CLK 100 MHz CORE_CLKOUTM4 / 2 pd_per_l4ls_gclk
Interface clock From PRCM
CLKSPIREF 48 MHz PER_CLKOUTM2 / 4 pd_per_spi_gclk
Functional clock From PRCM
24.2.3 McSPI Pin List
The McSPI interface pins are summarized in Table 24-4.
Table 24-4. McSPI Pin List
Pin Type Description
SPIx_SCLK I/O
(1)
SPI serial clock (output when master,
input when slave)
SPIx_D0 I/O Can be configured as either input or
output (MOSI or MISO)
SPIx_D1 I/O Can be configured as either input or
output (MOSI or MISO)
SPIx_CS0 I/O SPI chip select 0 output when master,
input when slave (active low)
SPIx_CS1 O SPI chip select 1 output when master,
input when slave (active low)
(1)
This
output
signal
is
also
used
as
a
re-timing
input.
The
associated
CONF_<module>_<pin>_RXACTIVE
bit
for
the
output
clock
must be set to 1 to enable the clock input back to the module.
