7.4.5.11 ELM_SYNDROME_FRAGMENT_3_i Register
The ELM_SYNDROME_FRAGMENT_3_i Register is shown in Figure 7-151 and described in Table 7-185.
Figure 7-151. ELM_SYNDROME_FRAGMENT_3_i Register
31 0
SYNDROME_3
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-185. ELM_SYNDROME_FRAGMENT_3_i Register Field Descriptions
Bit Field Value Description
31-0 SYNDROME_3 0-FFFF FFFFh Syndrome bits 96 to 127.
7.4.5.12 ELM_SYNDROME_FRAGMENT_4_i Register
The ELM_SYNDROME_FRAGMENT_4_i Register is shown in Figure 7-152 and described in Table 7-186.
Figure 7-152. ELM_SYNDROME_FRAGMENT_4_i Register
31 0
SYNDROME_4
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-186. ELM_SYNDROME_FRAGMENT_4_i Register Field Descriptions
Bit Field Value Description
31-0 SYNDROME_4 0-FFFF FFFFh Syndrome bits 128 to 159.
7.4.5.13 ELM_SYNDROME_FRAGMENT_5_i Register
The ELM_SYNDROME_FRAGMENT_5_i Register is shown in Figure 7-153 and described in Table 7-187.
Figure 7-153. ELM_SYNDROME_FRAGMENT_5_i Register
31 0
SYNDROME_5
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-187. ELM_SYNDROME_FRAGMENT_5_i Register Field Descriptions
Bit Field Value Description
31-0 SYNDROME_5 0-FFFF FFFFh Syndrome bits 160 to 191.
496
Memory Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
