7.1.5.8 GPMC_ERR_TYPE
The GPMC_ERR_TYPE register stores the type of error when an error occurs.
Figure 7-58. GPMC_ERR_TYPE
31 16
Reserved
R-0
15 11 10 8
Reserved ILLEGALMCMD
R-0 R/W-0
7 5 4 3 2 1 0
Reserved ERRORNOT ERRORNOT ERROR Reserved ERRORVALID
SUPPADD SUPPMCMD TIMEOUT
R-0 R/W-0 R/W-0 R/W-0 R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-62. GPMC_ERR_TYPE Field Descriptions
Bit Field Value Description
31-11 Reserved 0 Reserved
10-8 ILLEGALMCMD 0-7h System Command of the transaction that caused the error
7-5 Reserved 0 Reserved
4 ERRORNOTSUPPADD Not supported Address error
0 No error occurs
1 The error is due to a non supported Address
3 ERRORNOTSUPPMCMD Not supported Command error
0 No error occurs
1 The error is due to a non supported Command
2 ERRORTIMEOUT Time-out error
0 No error occurs
1 The error is due to a time out
1 Reserved 0 Reserved
0 ERRORVALID Error validity status - Must be explicitly cleared with a write 1 transaction
0 All error fields no longer valid
1 Error detected and logged in the other error fields
