CONTROL_MODULE Registers
www.ti.com
9.3.74 adc_evt_capt Register (offset = FD8h) [reset = 0h]
adc_evt_capt is shown in Figure 9-77 and described in Table 9-84.
Figure 9-77. adc_evt_capt Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved adc_evtcapt
R-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 9-84. adc_evt_capt Register Field Descriptions
Bit Field Type Reset Description
31-4 Reserved R 0h
3-0 adc_evtcapt R/W 0h ECAP0 event capture mux
838
Control Module SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
