Ethernet Subsystem Registers
www.ti.com
14.5.6.4 P0_TX_IN_CTL Register (offset = 10h) [reset = 40C0h]
P0_TX_IN_CTL is shown in Figure 14-124 and described in Table 14-139.
CPSW PORT 0 TRANSMIT FIFO CONTROL
Figure 14-124. P0_TX_IN_CTL Register
31 30 29 28 27 26 25 24
Reserved
23 22 21 20 19 18 17 16
TX_RATE_EN Reserved TX_IN_SEL
R/W-0h R/W-0h
15 14 13 12 11 10 9 8
TX_BLKS_REM Reserved TX_PRI_WDS
R/W-4h R/W-C0h
7 6 5 4 3 2 1 0
TX_PRI_WDS
R/W-C0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-139. P0_TX_IN_CTL Register Field Descriptions
Bit Field Type Reset Description
23-20 TX_RATE_EN R/W 0h
Transmit FIFO Input Rate Enable
17-16 TX_IN_SEL R/W 0h Transmit FIFO Input Queue Type Select
00 - Normal priority mode
01 - Dual MAC mode
10 - Rate Limit mode
11 - reserved Note that Dual MAC mode is not compatible with
escalation or shaping because dual mac mode forces round robin
priority on FIFO egress.
15-12 TX_BLKS_REM R/W 4h
Transmit FIFO Input Blocks to subtract in dual mac mode
9-0 TX_PRI_WDS R/W C0h
Transmit FIFO Words in queue
1360
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
