Ethernet Subsystem Registers
www.ti.com
14.5.8.6 SOFT_IDLE Register (offset = 14h) [reset = 0h]
SOFT_IDLE is shown in Figure 14-189 and described in Table 14-206.
SOFTWARE IDLE
Figure 14-189. SOFT_IDLE Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved SOF
T_ID
LE
R/
W-
0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-206. SOFT_IDLE Register Field Descriptions
Bit Field Type Reset Description
0 SOFT_IDLE R/W-0 0 Software Idle - Setting this bit causes the switch fabric to stop
forwarding packets at the next start of packet.
1430
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
