EDMA3 Registers
www.ti.com
11.4.2.7.4 Source Active Destination Address Register (SADST)
The source active destination address register (SADST) is shown in Figure 11-118 and described in
Table 11-103.
Figure 11-118. Source Active Destination Address Register (SADST)
31 16
Reserved
R-0
15 0
Reserved
R-0
LEGEND: R = Read only; -n = value after reset
Table 11-103. Source Active Destination Address Register (SADST) Field Descriptions
Bit Field Value Description
31-0 Reserve 0 Reserved. Always reads as 0.
d
11.4.2.7.5 Source Active Source B-Dimension Index Register (SABIDX)
The source active set B-dimension index register (SABIDX) is shown in Figure 11-119 and described in
Table 11-104.
Figure 11-119. Source Active Source B-Dimension Index Register (SABIDX)
31 16
DBIDX
R-0
15 0
SBIDX
R-0
LEGEND: R = Read only; -n = value after reset
Table 11-104. Source Active Source B-Dimension Index Register (SABIDX) Field Descriptions
Bit Field Value Description
31-16 DBIDX 0 B-Index offset between destination arrays. Represents the offset in bytes between the starting
address of each destination. Always reads as 0.
15-0 SBIDX 0-FFFFh B-Index offset between source arrays. Represents the offset in bytes between the starting address
of each source array.
1008
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
