www.ti.com McSPI Registers
24.4.1.4 McSPI Interrupt Status Register (MCSPI_IRQSTATUS)
The McSPI interrupt status register (MCSPI_IRQSTATUS) regroups all the status of the module internal
events that can generate an interrupt. The MCSPI_IRQSTATUS is shown in Figure 24-29 and described
in Table 24-14.
NOTE: In SYSTEST mode, the bits of this register have no meaning and always read 0.
Figure 24-29. McSPI Interrupt Status Register (MCSPI_IRQSTATUS)
31 18 17 16
Reserved EOW Rsvd
R/W-0 R/W-0 R-0
15 14 13 12 11 10 9 8
Rsvd RX3_FULL TX3_UNDERFLOW TX3_EMPTY Reserved RX2_FULL TX2_UNDERFLOW TX2_EMPTY
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 3 2 1 0
Rsvd RX1_FULL TX1_UNDERFLOW TX1_EMPTY RX0_OVERFLOW RX0_FULL TX0_UNDERFLOW TX0_EMPTY
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
Table 24-14. McSPI Interrupt Status Register (MCSPI_IRQSTATUS) Field Descriptions
Bit Field Value Description
31-18 Reserved 0 Reads returns 0
17 EOW End of word (EOW) count event when a channel is enabled using the FIFO buffer and the
channel has sent the number of McSPI words defined by the MCSPI_XFERLEVEL[WCNT].
Write 0 Event status bit is unchanged.
Read 0 Event false.
Write 1 Event status bit is reset.
Read 1 Event is pending.
16 Reserved 0 Reserved
15 Reserved 0 Reads returns 0
14 RX3_FULL Receiver register is full or almost full. Only when Channel 3 is enabled. This bit indicate
FIFO almost full status when built-in FIFO is used for receive register
(MCSPI_CH3CONF[FFE3R] is set).
Write 0 Event status bit is unchanged.
Read 0 Event false.
Write 1 Event status bit is reset.
Read 1 Event is pending.
13 TX3_UNDERFLOW Transmitter register underflow. Only when Channel 3 is enabled. The transmitter register is
empty (not updated by Host or DMA with new data) before its time slot assignment.
Exception: No TX_underflow event when no data has been loaded into the transmitter
register since channel has been enabled.
Write 0 Event status bit is unchanged.
Read 0 Event false.
Write 1 Event status bit is reset.
Read 1 Event is pending.
4037
