Ethernet Subsystem Registers
14.5.3.10 CPTS_EVENT_LOW Register (offset = 34h) [reset = 0h]
CPTS_EVENT_LOW is shown in Figure 14-87 and described in Table 14-99.
LOWER 32-BITS OF THE EVENT VALUE
Figure 14-87. CPTS_EVENT_LOW Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TIME_STAMP
R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-99. CPTS_EVENT_LOW Register Field Descriptions
Bit Field Type Reset Description
31-0 TIME_STAMP R 0h Time Stamp - The timestamp is valid for transmit, receive, and time
stamp push event types.
The timestamp value is not valid for counter roll event types.
1319
