9.3.3 control_sysconfig Register (offset = 10h) [reset = 0h]
control_sysconfig is shown in Figure 9-6 and described in Table 9-13.
Figure 9-6. control_sysconfig Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved standby idlemode freeemu Reserved
R-0h R-0h R/W-0h R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 9-13. control_sysconfig Register Field Descriptions
Bit Field Type Reset Description
31-6 Reserved R 0h
5-4 standby R 0h Configure local initiator state management
00: Force Standby
01: No Standby Mode
10: Smart Standby
11: Smart Standby wakeup capable
Reserved in Control Module since it has no local initiator.
3-2 idlemode R/W 0h Configure local target state management
00: Force Idle
01: No Idle
10: Smart Idle
11: Smart Idle wakeup capable
1 freeemu R 0h Sensitivity to Emulation suspend input.
0: Module is sensitive to EMU suspend
1: Module not sensitive to EMU suspend
0 Reserved R 0h
