7.4.5.5 ELM Interrupt Enable Register (ELM_IRQENABLE)
The ELM Interrupt Enable Register (ELM_IRQENABLE) is shown in Figure 7-145 and described in
Table 7-179.
Figure 7-145. ELM Interrupt Enable Register (ELM_IRQENABLE)
31 16
Reserved
R-0
15 9 8
Reserved PAGE_MASK
R-0 R/W-0
7 6 5 4 3 2 1 0
LOCATION_ LOCATION_ LOCATION_ LOCATION_ LOCATION_ LOCATION_ LOCATION_ LOCATION_
MASK_7 MASK_6 MASK_5 MASK_4 MASK_3 MASK_2 MASK_1 MASK_0
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-179. ELM Interrupt Enable Register (ELM_IRQENABLE) Field Descriptions
Bit Field Value Description
31-9 Reserved 0 Reserved
8 PAGE_MASK Page interrupt mask bit
0 Disable interrupt.
1 Enable interrupt.
7 LOCATION_MASK_7 Error-location interrupt mask bit for syndrome polynomial 7.
0 Disable interrupt.
1 Enable interrupt.
6 LOCATION_MASK_6 Error-location interrupt mask bit for syndrome polynomial 6.
0 Disable interrupt.
1 Enable interrupt.
5 LOCATION_MASK_5 Error-location interrupt mask bit for syndrome polynomial 5.
0 Disable interrupt.
1 Enable interrupt.
4 LOCATION_MASK_4 Error-location interrupt mask bit for syndrome polynomial 4.
0 Disable interrupt.
1 Enable interrupt.
3 LOCATION_MASK_3 Error-location interrupt mask bit for syndrome polynomial 3.
0 Disable interrupt.
1 Enable interrupt.
2 LOCATION_MASK_2 Error-location interrupt mask bit for syndrome polynomial 2.
0 Disable interrupt.
1 Enable interrupt.
1 LOCATION_MASK_1 Error-location interrupt mask bit for syndrome polynomial 1.
0 Disable interrupt.
1 Enable interrupt.
0 LOCATION_MASK_0 Error-location interrupt mask bit for syndrome polynomial 0.
0 Disable interrupt.
1 Enable interrupt.
492
Memory Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
