USB Registers
www.ti.com
16.5.7.16 PEND2 Register (offset = 98h) [reset = 0h]
PEND2 is shown in Figure 16-292 and described in Table 16-306.
Figure 16-292. PEND2 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
QPEND2
R-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-306. PEND2 Register Field Descriptions
Bit Field Type Reset Description
31-0 QPEND2 R-0 0 This field indicates the queue pending status for queues[
95:64].
Queue_Manager_Queue_Pending_2 Register 2
2124
Universal Serial Bus (USB) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
