www.ti.com
RTC_SS
20.3.5.29 ALARM2_MINUTES_REG Register (offset = 84h) [reset = 0h]
ALARM2_MINUTES_REG is shown in Figure 20-89 and described in Table 20-92.
The ALARM2_MINUTES_REG is used to program the minute value for the alarm2 time. Minutes are
stored as BCD format. In BCD format, the decimal numbers 0 through 9 are encoded with their binary
equivalent.
Figure 20-89. ALARM2_MINUTES_REG Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved ALARM2_MIN1 ALARM2_MIN0
R-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 20-92. ALARM2_MINUTES_REG Register Field Descriptions
Bit Field Type Reset Description
31-7 Reserved R 0h
6-4 ALARM2_MIN1 R/W 0h
2nd digit of minutes, Range is 0 to 5
3-0 ALARM2_MIN0 R/W 0h
1st digit of minutes, Range is 0 to 9
3663
SPRUH73H–October 2011–Revised April 2013 Timers
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
