CONTROL_MODULE Registers
www.ti.com
9.3.1 control_revision Register (offset = 0h) [reset = 0h]
control_revision is shown in Figure 9-4 and described in Table 9-11.
Figure 9-4. control_revision Register
31 30 29 28 27 26 25 24
ip_rev_scheme Reserved ip_rev_func
R-0h R-0h R-0h
23 22 21 20 19 18 17 16
ip_rev_func
R-0h
15 14 13 12 11 10 9 8
ip_rev_rtl ip_rev_major
R-0h R-0h
7 6 5 4 3 2 1 0
ip_rev_custom ip_rev_minor
R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 9-11. control_revision Register Field Descriptions
Bit Field Type Reset Description
31-30 ip_rev_scheme R 0h 01 - New Scheme
29-28 Reserved R 0h
27-16 ip_rev_func R 0h Function indicates a software compatible module family.
If there is no level of software compatibility a new Func number (and
hence REVISION) should be assigned.
15-11 ip_rev_rtl R 0h RTL Version (R).
10-8 ip_rev_major R 0h Major Revision (X).
7-6 ip_rev_custom R 0h Indicates a special version for a particular device. Consequence of
use may avoid use of standard Chip Support Library (CSL) / Drivers
-
00: Non custom (standard) revision
5-0 ip_rev_minor R 0h Minor Revision (Y).
762
Control Module SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
