Ethernet Subsystem Registers
www.ti.com
14.5.6.25 P1_SA_HI Register (offset = 124h) [reset = 0h]
P1_SA_HI is shown in Figure 14-145 and described in Table 14-160.
CPSW CPGMAC_SL1 SOURCE ADDRESS HIGH REGISTER
Figure 14-145. P1_SA_HI Register
31 30 29 28 27 26 25 24
MACSRCADDR_23_16
R/W-0h
23 22 21 20 19 18 17 16
MACSRCADDR_31_24
R/W-0h
15 14 13 12 11 10 9 8
MACSRCADDR_39_32
R/W-0h
7 6 5 4 3 2 1 0
MACSRCADDR_47_40
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-160. P1_SA_HI Register Field Descriptions
Bit Field Type Reset Description
31-24 MACSRCADDR_23_16 R/W 0h Source Address bits
23:16 (byte 2)
23-16 MACSRCADDR_31_24 R/W 0h Source Address bits
31:24 (byte 3)
15-8 MACSRCADDR_39_32 R/W 0h Source Address bits
39:32 (byte 4)
7-0 MACSRCADDR_47_40 R/W 0h Source Address bits
47:40 (byte 5)
1382
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
