www.ti.com
LCD Registers
13.5.20 LCDDMA_FB1_CEILING Register (offset = 50h) [reset = 0h]
LCDDMA_FB1_CEILING is shown in Figure 13-38 and described in Table 13-33.
Figure 13-38. LCDDMA_FB1_CEILING Register
31 30 29 28 27 26 25 24
fb1_ceil
R/W-0h
23 22 21 20 19 18 17 16
fb1_ceil
R/W-0h
15 14 13 12 11 10 9 8
fb1_ceil
R/W-0h
7 6 5 4 3 2 1 0
fb1_ceil Reserved
R/W-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 13-33. LCDDMA_FB1_CEILING Register Field Descriptions
Bit Field Type Reset Description
31-2 fb1_ceil R/W 0h
Frame Buffer 1 Ceiling Address pointer
1-0 Reserved R 0h
1151
SPRUH73H–October 2011–Revised April 2013 LCD Controller
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
