I2C Registers
21.4.1.12 I2C_DMATXENABLE_CLR Register (offset = 44h) [reset = 0h]
I2C_DMATXENABLE_CLR is shown in Figure 21-27 and described in Table 21-20.
The 1-bit field disables a transmit DMA request. Writing a 1 to a bit will clear it to 0. Another result of
setting to 1 the DMATX_ENABLE_CLEAR field, is the reset of the DMA TX request and wakeup lines.
Writing a 0 will have no effect, that is, the register value is not modified.
Figure 21-27. I2C_DMATXENABLE_CLR Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved DMARX_ENABLE_CL
EAR
R-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 21-20. I2C_DMATXENABLE_CLR Register Field Descriptions
Bit Field Type Reset Description
31-1 Reserved R 0h
0 DMARX_ENABLE_CLEA R/W 0h
Receive DMA channel enable clear.
R
3739
SPRUH73H–October 2011–Revised April 2013 I2C
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
