8.1.12.3.6 CLKSEL_TIMER5_CLK Register (offset = 18h) [reset = 1h]
CLKSEL_TIMER5_CLK is shown in Figure 8-143 and described in Table 8-152.
Selects the Mux select line for TIMER5 clock [warm reset insensitive]
Figure 8-143. CLKSEL_TIMER5_CLK Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved CLKSEL
R-0h R/W-1h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 8-152. CLKSEL_TIMER5_CLK Register Field Descriptions
Bit Field Type Reset Description
31-2 Reserved R 0h
1-0 CLKSEL R/W 1h
Selects the Mux select line for TIMER5 clock [warm reset insensitive]
0x0 = SEL1 : Select TCLKIN clock
0x1 = SEL2 : Select CLK_M_OSC clock
0x2 = SEL3 : Select CLK_32KHZ clock
0x3 = SEL4 : Reserved
