www.ti.com
Power, Reset, and Clock Management
8.1.12.2.30 CM_SSC_DELTAMSTEP_DPLL_PER Register (offset = 74h) [reset = 0h]
CM_SSC_DELTAMSTEP_DPLL_PER is shown in Figure 8-113 and described in Table 8-121.
Control the DeltaMStep parameter for Spread Spectrum Clocking technique DeltaMStep is split into
fractional and integer part. [warm reset insensitive]
Figure 8-113. CM_SSC_DELTAMSTEP_DPLL_PER Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved DELTAMSTEP_INTEGER DELTAMSTEP_FRACTION
R-0h R/W-0h R/W-0h
15 14 13 12 11 10 9 8
DELTAMSTEP_FRACTION
R/W-0h
7 6 5 4 3 2 1 0
DELTAMSTEP_FRACTION
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 8-121. CM_SSC_DELTAMSTEP_DPLL_PER Register Field Descriptions
Bit Field Type Reset Description
31-20 Reserved R 0h
19-18 DELTAMSTEP_INTEGER R/W 0h
Integer part for DeltaM coefficient
17-0 DELTAMSTEP_FRACTIO R/W 0h
Fractional setting for DeltaMStep parameter
N
645
SPRUH73H–October 2011–Revised April 2013 Power, Reset, and Clock Management (PRCM)
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
