Ethernet Subsystem Registers
www.ti.com
14.5.9.28 C2_MISC_STAT Register (offset = 6Ch) [reset = 0h]
C2_MISC_STAT is shown in Figure 14-224 and described in Table 14-242.
SUBSYSTEM CORE 2 MISC MASKED INTERRUPT STATUS REGISTER
Figure 14-224. C2_MISC_STAT Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved C2_MISC_STAT
R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-242. C2_MISC_STAT Register Field Descriptions
Bit Field Type Reset Description
31-5 Reserved R 0h
4-0 C2_MISC_STAT R 0h Core 2 Misc Masked Interrupt Status - Each bit in this register
corresponds to the miscellaneous interrupt (evnt_pend, stat_pend,
host_pend, mdio_linkint, mdio_userint) that is enabled and
generating an interrupt on C2_MISC_PULSE.
Bit 4 = evnt_pend
Bit 3 = stat_pend
Bit 2 = host_pend
Bit 1 = mdio_linkint
Bit 0 = mdio_userint
1466
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
