Touchscreen Controller Registers
www.ti.com
12.5.1.18 TS_CHARGE_DELAY Register (offset = 60h) [reset = 1h]
TS_CHARGE_DELAY is shown in Figure 12-22 and described in Table 12-22.
TS Charge Delay Register@TSC_ADC_SS_TS_Charge_StepDelay Register
Figure 12-22. TS_CHARGE_DELAY Register
31 30 29 28 27 26 25 24
Reserved
R/W-0h
23 22 21 20 19 18 17 16
Reserved OpenDelay
R/W-0h R/W-1h
15 14 13 12 11 10 9 8
OpenDelay
R/W-1h
7 6 5 4 3 2 1 0
OpenDelay
R/W-1h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-22. TS_CHARGE_DELAY Register Field Descriptions
Bit Field Type Reset Description
31-18 Reserved R/W 0h
17-0 OpenDelay R/W 1h Program the # of ADC clock cycles to wait between applying the
step configuration registers and going back to the IDLE state.
(Value must be greater than 0.)
1056
Touchscreen Controller SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
