16.5.7.1124 QUEUE_155_STATUS_A Register (offset = 39B0h) [reset = 0h]
QUEUE_155_STATUS_A is shown in Figure 16-1400 and described in Table 16-1414.
Figure 16-1400. QUEUE_155_STATUS_A Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved QUEUE_ENTRY_COUNT
R-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-1414. QUEUE_155_STATUS_A Register Field Descriptions
Bit Field Type Reset Description
13-0 QUEUE_ENTRY_COUNT R-0 0 This field indicates how many packets are currently queued on the
queue.
Queue Manager Queue N Status Registers A
3232
