CONTROL_MODULE Registers
www.ti.com
9.3.10 bandgap_trim Register (offset = 44Ch) [reset = 0h]
bandgap_trim is shown in Figure 9-13 and described in Table 9-20.
Figure 9-13. bandgap_trim Register
31 30 29 28 27 26 25 24
dtrbgapc
R/W-0h
23 22 21 20 19 18 17 16
dtrbgapv
R/W-0h
15 14 13 12 11 10 9 8
dtrtemps
R/W-0h
7 6 5 4 3 2 1 0
dtrtempsc
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 9-20. bandgap_trim Register Field Descriptions
Bit Field Type Reset Description
31-24 dtrbgapc R/W 0h trim the output voltage of bandgap
23-16 dtrbgapv R/W 0h trim the output voltage of bandgap
15-8 dtrtemps R/W 0h trim the temperature sensor
7-0 dtrtempsc R/W 0h trim the temperature sensor
772
Control Module SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
