20.1.2.4 Timer Pin List
The timer PIEVENTCAPT input and PORTIMERPWM output signals are muxed onto a single TIMER I/O
pad. The pad direction (and hence the pin function) are controlled from within the DMTimer module using
the PORGPOCFG signal as an output enable.
Table 20-5. Timer Pin List
Pin Type Description
TCLKIN I External timer clock source
TIMER4 I/O Timer 4 trigger input or PWM output
TIMER5 I/O Timer 5 trigger input or PWM output
TIMER6 I/O Timer 6 trigger input or PWM output
TIMER7 I/O Timer 7 trigger input or PWM output
