GPIO Registers
www.ti.com
25.4.1.4 GPIO_IRQSTATUS_RAW_0 Register (offset = 24h) [reset = 0h]
GPIO_IRQSTATUS_RAW_0 is shown in Figure 25-10 and described in Table 25-9.
The GPIO_IRQSTATUS_RAW_0 register provides core status information for the interrupt handling,
showing all active events (enabled and not enabled). The fields are read-write. Writing a 1 to a bit sets it
to 1, that is, triggers the IRQ (mostly for debug). Writing a 0 has no effect, that is, the register value is not
be modified. Only enabled, active events trigger an actual interrupt request on the IRQ output line.
Figure 25-10. GPIO_IRQSTATUS_RAW_0 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
INTLINE[n]
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 25-9. GPIO_IRQSTATUS_RAW_0 Register Field Descriptions
Bit Field Type Reset Description
31-0 INTLINE[n] R/W 0h
Interrupt n status.
0x0 = No effect.
0x1 = IRQ is triggered.
4072
General-Purpose Input/Output SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
