USB Registers www.ti.com
16.5.3.13 USB1TXMODE Register (offset = 70h) [reset = 0h]
USB1TXMODE is shown in Figure 16-111 and described in Table 16-121.
Figure 16-111. USB1TXMODE Register
31 30 29 28 27 26 25 24
Reserved TX15_MODE TX14_MODE TX13_MODE
R/W-0h R/W-0h R/W-0h
23 22 21 20 19 18 17 16
TX12_MODE TX11_MODE TX10_MODE TX9_MODE
R/W-0h R/W-0h R/W-0h R/W-0h
15 14 13 12 11 10 9 8
TX8_MODE TX7_MODE TX6_MODE TX5_MODE
R/W-0h R/W-0h R/W-0h R/W-0h
7 6 5 4 3 2 1 0
TX4_MODE TX3_MODE TX2_MODE TX1_MODE
R/W-0h R/W-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-121. USB1TXMODE Register Field Descriptions
Bit Field Type Reset Description
29-28 TX15_MODE R/W 0h 00: Transparent Mode on TX endpoint 14
01: RNDIS Mode on TX endpoint 14
10: CDC Mode on TX endpoint 14
11: Generic RNDIS Mode on TX endpoint 14
27-26 TX14_MODE R/W 0h 00: Transparent Mode on TX endpoint 13
01: RNDIS Mode on TX endpoint 13
10: CDC Mode on TX endpoint 13
11: Generic RNDIS Mode on TX endpoint 13
25-24 TX13_MODE R/W 0h 00: Transparent Mode on TX endpoint 12
01: RNDIS Mode on TX endpoint 12
10: CDC Mode on TX endpoint 12
11: Generic RNDIS Mode on TX endpoint 12
23-22 TX12_MODE R/W 0h 00: Transparent Mode on TX endpoint 11
01: RNDIS Mode on TX endpoint 11
10: CDC Mode on TX endpoint 11
11: Generic RNDIS Mode on TX endpoint 11
21-20 TX11_MODE R/W 0h 00: Transparent Mode on TX endpoint 10
01: RNDIS Mode on TX endpoint 10
10: CDC Mode on TX endpoint 10
11: Generic RNDIS Mode on TX endpoint 10
19-18 TX10_MODE R/W 0h 00: Transparent Mode on TX endpoint 9
01: RNDIS Mode on TX endpoint 9
10: CDC Mode on TX endpoint 9
11: Generic RNDIS Mode on TX endpoint 9
17-16 TX9_MODE R/W 0h 00: Transparent Mode on TX endpoint 8
01: RNDIS Mode on TX endpoint 8
10: CDC Mode on TX endpoint 8
11: Generic RNDIS Mode on TX endpoint 8
15-14 TX8_MODE R/W 0h 00: Transparent Mode on TX endpoint 7
01: RNDIS Mode on TX endpoint 7
10: CDC Mode on TX endpoint 7
11: Generic RNDIS Mode on TX endpoint 7
13-12 TX7_MODE R/W 0h 00: Transparent Mode on TX endpoint 6
01: RNDIS Mode on TX endpoint 6
10: CDC Mode on TX endpoint 6
11: Generic RNDIS Mode on TX endpoint 6
