www.ti.com
USB Registers
Table 16-121. USB1TXMODE Register Field Descriptions (continued)
Bit Field Type Reset Description
11-10 TX6_MODE R/W 0h 00: Transparent Mode on TX endpoint 5
01: RNDIS Mode on TX endpoint 5
10: CDC Mode on TX endpoint 5
11: Generic RNDIS Mode on TX endpoint 5
9-8 TX5_MODE R/W 0h 00: Transparent Mode on TX endpoint 4
01: RNDIS Mode on TX endpoint 4
10: CDC Mode on TX endpoint 4
11: Generic RNDIS Mode on TX endpoint 4
7-6 TX4_MODE R/W 0h 00: Transparent Mode on TX endpoint 3
01: RNDIS Mode on TX endpoint 3
10: CDC Mode on TX endpoint 3
11: Generic RNDIS Mode on TX endpoint 3
5-4 TX3_MODE R/W 0h 00: Transparent Mode on TX endpoint 2
01: RNDIS Mode on TX endpoint 2
10: CDC Mode on TX endpoint 2
11: Generic RNDIS Mode on TX endpoint 2
3-2 TX2_MODE R/W 0h 00: Transparent Mode on TX endpoint 1
01: RNDIS Mode on TX endpoint 1
10: CDC Mode on TX endpoint 1
11: Generic RNDIS Mode on TX endpoint 1
1-0 TX1_MODE R/W 0h 00: Transparent Mode on TX endpoint 0
01: RNDIS Mode on TX endpoint 0
10: CDC Mode on TX endpoint 0
11: Generic RNDIS Mode on TX endpoint 0 USB1 Tx Mode
Registers
1877
SPRUH73H–October 2011–Revised April 2013 Universal Serial Bus (USB)
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
