www.ti.com
Functional Description
if (Broadcast packet)
then use found vlan_member_list and goto Egress process
14.3.2.7.2.4 Egress Process
Clear Rx port from portmask (don’t send packet to Rx port).
Clear disabled ports from portmask.
if ((enable_oui_deny) and (OUI source address not found) and (not ale_bypass) and (not error packet) and not ((mcast destination
address) and (super)))
then Clear host port from portmask
if ((enable_rate_limit) and (rate_limit_tx))
then if (not super) and (rate limit exceeded on any tx port)
then clear rate limited tx port from portmask
If address not found then super cannot be set.
If portmask is zero then discard packet
Send packet to portmask ports.
14.3.2.7.3 Learning/Updating/Touching Processes
The learning, updating, and touching processes are applied to each receive packet that is not aborted.
The processes are concurrent with the packet forwarding process. In addition to the following, a packet
must be received without error in order to learn/update/touch an address.
14.3.2.7.3.1 Learning Process
If (not(Learning or Forwarding) or (enable_auth_mode) or (packet error) or (no_learn))
then do not learn address
if ((Non-tagged packet) and (drop_untagged))
then do not learn address
if ((vlan_aware) and (VLAN not found) and (unknown_vlan_member_list = “000”))
then do not learn address
if ((vid_ingress_check) and (Rx port is not VLAN member) and (VLAN found))
then do not learn address
if ((source address not found) and (vlan_aware) and not(learn_no_vid))
then learn address with VLAN
if ((source address not found) and ((not vlan_aware) or (vlan_aware and learn_no_vid)))
then learn address without VLAN
14.3.2.7.3.2 Updating Process
if (dlr_unicast)
then do not update address
If (not(Learning or Forwarding) or (enable_auth_mode) or (packet error) or (no_sa_update))
then do not update address
if ((Non-tagged packet) and (drop_untagged))
then do not update address
if ((vlan_aware) and (VLAN not found) and (unknown_vlan_member_list = “000”))
then do not update address
1203
SPRUH73HOctober 2011Revised April 2013 Ethernet Subsystem
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
