Texas Instruments AM335 Series Technical Reference Manual

www.ti.com LCD Registers
13.5.25 IRQENABLE_CLEAR Register (offset = 64h) [reset = 0h]
IRQENABLE_CLEAR is shown in Figure 13-43 and described in Table 13-38.
Figure 13-43. IRQENABLE_CLEAR Register
31 30 29 28 27 26 25 24
Reserved
R/W-0h
23 22 21 20 19 18 17 16
Reserved
R/W-0h
15 14 13 12 11 10 9 8
Reserved eof1_en_clr eof0_en_clr
R/W-0h R/W-0h R/W-0h
7 6 5 4 3 2 1 0
Reserved pl_en_clr fuf_en_clr Reserved acb_en_clr sync_en_clr recurrent_raster_done done_en_clr
_en_clr
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 13-38. IRQENABLE_CLEAR Register Field Descriptions
Bit Field Type Reset Description
31-10 Reserved R/W 0h
9 eof1_en_clr R/W 0h DMA End-of-Frame 1 Interrupt Enable Clear Read indicates enabled
status
0 = disabled 1 = enabled Writing 1 will clear interrupt enable
Writing 0 has no effect
8 eof0_en_clr R/W 0h DMA End-of-Frame 0 Interrupt Enable Clear Read indicates enabled
status 0 = disabled 1 = enabled Writing 1 will clear interrupt enable
Writing 0 has no effect
7 Reserved R/W 0h
6 pl_en_clr R/W 0h DMA Palette Loaded Interrupt Enable Clear Read indicates enabled
status
0 = disabled 1 = enabled Writing 1 will clear interrupt enable
Writing 0 has no effect
5 fuf_en_clr R/W 0h DMA FIFO Underflow Interrupt Enable Clear LCD dithering logic not
supplying data to FIFO at a sufficient rate, FIFO has completely
emptied and data pin driver logic has attempted to take added data
from FIFO
Read indicates enabled status
0 = disabled 1 = enabled Writing 1 will clear interrupt enable
Writing 0 has no effect
4 Reserved R/W 0h
3 acb_en_clr R/W 0h For Passive Matrix Panels Only AC Bias Count Interrupt Enable
Clear AC bias transition counter has decremented to zero, indicating
that the lcd_ac_o line has transitioned the number of times which is
specified by the acbi control bit-field
The counter is reloaded with the value in acbi but it is disabled until
the user clears ABC
Read indicates enabled status
0 = disabled 1 = enabled Writing 1 will clear interrupt enable
Writing 0 has no effect
2 sync_en_clr R/W 0h Frame Synchronization Lost Interrupt Enable Clear Read indicates
enabled status 0 = disabled 1 = enabled Writing 1 will clear interrupt
enable
Writing 0 has no effect
1159
SPRUH73H–October 2011–Revised April 2013 LCD Controller
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
