Ethernet Subsystem Registers
14.5.6.41 P2_TS_SEQ_MTYPE Register (offset = 21Ch) [reset = 1E0000h]
P2_TS_SEQ_MTYPE is shown in Figure 14-161 and described in Table 14-176.
CPSW_3GF PORT 2 TIME SYNC SEQUENCE ID OFFSET AND MSG TYPE.
Figure 14-161. P2_TS_SEQ_MTYPE Register
31 30 29 28 27 26 25 24
Reserved
23 22 21 20 19 18 17 16
Reserved P2_TS_SEQ_ID_OFFSET
R/W-1Eh
15 14 13 12 11 10 9 8
P2_TS_MSG_TYPE_EN
R/W-0h
7 6 5 4 3 2 1 0
P2_TS_MSG_TYPE_EN
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-176. P2_TS_SEQ_MTYPE Register Field Descriptions
Bit Field Type Reset Description
21-16 P2_TS_SEQ_ID_OFFSET R/W 1Eh Port 2 Time Sync Sequence ID Offset This is the number of octets
that the sequence ID is offset in the tx and rx time sync message
header.
The minimum value is 6.
15-0 P2_TS_MSG_TYPE_EN R/W 0h Port 2 Time Sync Message Type Enable - Each bit in this field
enables the corresponding message type in receive and transmit
time sync messages (Bit 0 enables message type 0 etc.).
1399
SPRUH73H–October 2011–Revised April 2013 Ethernet Subsystem
