16.5.7.18 PEND4 Register (offset = A0h) [reset = 0h]
PEND4 is shown in Figure 16-294 and described in Table 16-308.
Figure 16-294. PEND4 Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
QPEND4
R-0
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 16-308. PEND4 Register Field Descriptions
Bit Field Type Reset Description
31-0 QPEND4 R-0 0 This field indicates the queue pending status for queues[
159:128].
Queue_Manager_Queue_Pending_4 Register 4
2126
Universal Serial Bus (USB) SPRUH73H–October 2011–Revised April 2013
