Ethernet Subsystem Registers
www.ti.com
14.5.7.1 IDVER Register (offset = 0h) [reset = 170112h]
IDVER is shown in Figure 14-173 and described in Table 14-189.
CPGMAC_SL ID/VERSION REGISTER
Figure 14-173. IDVER Register
31 30 29 28 27 26 25 24
IDENT
R-17h
23 22 21 20 19 18 17 16
IDENT
R-17h
15 14 13 12 11 10 9 8
Z X
R-2E0h R-1701h
7 6 5 4 3 2 1 0
Y
R-170112h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 14-189. IDVER Register Field Descriptions
Bit Field Type Reset Description
31-16 IDENT R 17h
Rx Identification Value
15-11 Z R 2E0h
Rx Z value (X.Y.Z)
10-8 X R 1701h
Rx X value (major)
7-0 Y R 170112h
Rx Y value (minor)
1412
Ethernet Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
