9.3.38 hw_event_sel_grp4 Register (offset = 69Ch) [reset = 0h]
hw_event_sel_grp4 is shown in Figure 9-41 and described in Table 9-48.
Figure 9-41. hw_event_sel_grp4 Register
31 30 29 28 27 26 25 24
event16
R/W-0h
23 22 21 20 19 18 17 16
event15
R/W-0h
15 14 13 12 11 10 9 8
event14
R/W-0h
7 6 5 4 3 2 1 0
event13
R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 9-48. hw_event_sel_grp4 Register Field Descriptions
Bit Field Type Reset Description
31-24 event16 R/W 0h Select 16th trace event from group 4
23-16 event15 R/W 0h Select 15th trace event from group 4
15-8 event14 R/W 0h Select 14th trace event from group 4
7-0 event13 R/W 0h Select 13th trace event from group 4
802
Control Module SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
