USB Registers
www.ti.com
16.5 USB Registers
16.5.1 USBSS Registers
Table 16-29 lists the memory-mapped registers for the USBSS. All register offset addresses not listed in
Table 16-29 should be considered as reserved locations and the register contents should not be modified.
Table 16-29. USBSS REGISTERS
Offset Acronym Register Name Section
0h REVREG Section 16.5.1.1
10h SYSCONFIG Section 16.5.1.2
24h IRQSTATRAW Section 16.5.1.3
28h IRQSTAT Section 16.5.1.4
2Ch IRQENABLER Section 16.5.1.5
30h IRQCLEARR Section 16.5.1.6
100h IRQDMATHOLDTX00 Section 16.5.1.7
104h IRQDMATHOLDTX01 Section 16.5.1.8
108h IRQDMATHOLDTX02 Section 16.5.1.9
10Ch IRQDMATHOLDTX03 Section 16.5.1.10
110h IRQDMATHOLDRX00 Section 16.5.1.11
114h IRQDMATHOLDRX01 Section 16.5.1.12
118h IRQDMATHOLDRX02 Section 16.5.1.13
11Ch IRQDMATHOLDRX03 Section 16.5.1.14
120h IRQDMATHOLDTX10 Section 16.5.1.15
124h IRQDMATHOLDTX11 Section 16.5.1.16
128h IRQDMATHOLDTX12 Section 16.5.1.17
12Ch IRQDMATHOLDTX13 Section 16.5.1.18
130h IRQDMATHOLDRX10 Section 16.5.1.19
134h IRQDMATHOLDRX11 Section 16.5.1.20
138h IRQDMATHOLDRX12 Section 16.5.1.21
13Ch IRQDMATHOLDRX13 Section 16.5.1.22
140h IRQDMAENABLE0 Section 16.5.1.23
144h IRQDMAENABLE1 Section 16.5.1.24
200h IRQFRAMETHOLDTX00 Section 16.5.1.25
204h IRQFRAMETHOLDTX01 Section 16.5.1.26
208h IRQFRAMETHOLDTX02 Section 16.5.1.27
20Ch IRQFRAMETHOLDTX03 Section 16.5.1.28
210h IRQFRAMETHOLDRX00 Section 16.5.1.29
214h IRQFRAMETHOLDRX01 Section 16.5.1.30
218h IRQFRAMETHOLDRX02 Section 16.5.1.31
21Ch IRQFRAMETHOLDRX03 Section 16.5.1.32
220h IRQFRAMETHOLDTX10 Section 16.5.1.33
224h IRQFRAMETHOLDTX11 Section 16.5.1.34
228h IRQFRAMETHOLDTX12 Section 16.5.1.35
22Ch IRQFRAMETHOLDTX13 Section 16.5.1.36
230h IRQFRAMETHOLDRX10 Section 16.5.1.37
234h IRQFRAMETHOLDRX11 Section 16.5.1.38
238h IRQFRAMETHOLDRX12 Section 16.5.1.39
23Ch IRQFRAMETHOLDRX13 Section 16.5.1.40
240h IRQFRAMEENABLE0 Section 16.5.1.41
244h IRQFRAMEENABLE1 Section 16.5.1.42
1760
Universal Serial Bus (USB) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
