PWM Events
6.4 PWM Events
Table 6-2. Timer and eCAP Event Capture
Event # IP Interrupt Name/Pin
For Timer 5 MUX input from IO signal TIMER5 IO pin
TIMER5
For Timer 6 MUX input from IO signal TIMER6 IO pin
TIMER6
0 For Timer 7 MUX input from IO signal TIMER7 IO pin
TIMER7
For eCAP 0 MUX input from IO signal eCAP0 IO pin
eCAP0
For eCAP 1 MUX input from IO signal eCAP1 IO pin
eCAP1
For eCAP 2 MUX input from IO signal eCAP2 IO pin
eCAP2
1 UART0 UART0INT
2 UART1 UART1INT
3 UART2 UART2INT
4 UART3 UART3INT
5 UART4 UART4INT
6 UART5 UART5INT
7 3PGSW 3PGSWRXTHR0
8 3PGSW 3PGSWRXINT0
9 3PGSW 3PGSWTXINT0
10 3PGSW 3PGSWMISC0
11 McASP0 MCATXINT0
12 McASP0 MCARXINT0
13 McASP1 MCATXINT1
14 McASP1 MCARXINT1
15 Reserved Reserved
16 Reserved Reserved
17 GPIO 0 GPIOINT0A
18 GPIO 0 GPIOINT0B
19 GPIO 1 GPIOINT1A
20 GPIO 1 GPIOINT1B
21 GPIO 2 GPIOINT2A
22 GPIO 2 GPIOINT2B
23 GPIO 3 GPIOINT3A
24 GPIO 3 GPIOINT3B
25 DCAN0 DCAN0_INT0
26 DCAN0 DCAN0_INT1
27 DCAN0 DCAN0_PARITY
28 DCAN1 DCAN1_INT0
29 DCAN1 DCAN1_INT1
30 DCAN1 DCAN1_PARITY
