www.ti.com Power, Reset, and Clock Management
8.1.13.1.2 PRM_IRQSTATUS_MPU Register (offset = 4h) [reset = 0h]
PRM_IRQSTATUS_MPU is shown in Figure 8-165 and described in Table 8-180.
This register provides status on MPU interrupt events. An event is logged whether interrupt generation for
the event is enabled or not. SW is required to clear a set bit by writing a '1' into the bit-position to be
cleared.
Figure 8-165. PRM_IRQSTATUS_MPU Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
dpll_per_recal_st dpll_ddr_recal_st dpll_disp_recal_st dpll_core_recal_st dpll_mpu_recal_st ForceWkup_st Reserved Transition_st
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R-0h R/W-0h
7 6 5 4 3 2 1 0
Reserved
R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 8-180. PRM_IRQSTATUS_MPU Register Field Descriptions
Bit Field Type Reset Description
31-16 Reserved R 0h
15 dpll_per_recal_st R/W 0h
interrupt status for usb dpll recaliberation
0 = DIS : Disables dpll recaliberation
1 = EN : ENAbles dpll recaliberation
14 dpll_ddr_recal_st R/W 0h
interrupt status for ddr dpll recaliberation
0 = DIS : Disables dpll recaliberation
1 = EN : ENAbles dpll recaliberation
13 dpll_disp_recal_st R/W 0h
interrupt status for disp dpll recaliberation
0 = DIS : Disables dpll recaliberation
1 = EN : ENAbles dpll recaliberation
12 dpll_core_recal_st R/W 0h
interrupt status for core dpll recaliberation
0 = DIS : Disables dpll recaliberation
1 = EN : ENAbles dpll recaliberation
11 dpll_mpu_recal_st R/W 0h
interrupt status for mpu dpll recaliberation
0 = DIS : Disables dpll recaliberation
1 = EN : ENAbles dpll recaliberation
10 ForceWkup_st R/W 0h
Software supervised wakeup completed event interrupt status
0 = IRQ_fal : No interrupt
1 = IRQ_tru : Interrupt is pending
9 Reserved R 0h
8 Transition_st R/W 0h
Software supervised transition completed event interrupt status (any
domain)
0 = IRQ_fal : No interrupt
1 = IRQ_tru : Interrupt is pending
7-0 Reserved R 0h
