Texas Instruments AM335 Series Technical Reference Manual

EDMA3 Registers www.ti.com
11.4.1.3 Region Access Enable Registers
The region access enable register group consists of the DMA access enable registers (DRAEm and
DRAEHm) and the QDMA access enable registers (QRAEm). Where m is the number of shadow regions
in the EDMA3CC memory map for a device. You can configure these registers to assign ownership of
DMA/QDMA channels to a particular shadow region.
11.4.1.3.1 DMA Region Access Enable for Region m (DRAEm)
The DMA region access enable register for shadow region m (DRAEm/DRAEHm) is programmed to allow
or disallow read/write accesses on a bit-by-bit bases for all DMA registers in the shadow region m view of
the DMA channel registers. See the EDMA3CC register memory map (Table 11-25) for a list of all the
DMA channel and interrupt registers mapped in the shadow region view. Additionally, the
DRAEm/DRAEHm configuration determines completion of which DMA channels will result in assertion of
the shadow region m DMA completion interrupt (see EDMA3 Interrupts).
The DRAEm is shown in Figure 11-59 and described in Table 11-44. The DRAEHm is shown in Figure 11-
60 and described in Table 11-44.
Figure 11-59. DMA Region Access Enable Register for Region m (DRAEm)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
E31 E30 E29 E28 E27 E26 E25 E24 E23 E22 E21 E20 E19 E18 E17 E16
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
LEGEND: R/W = Read/Write; -n = value after reset
Figure 11-60. DMA Region Access Enable High Register for Region m (DRAEHm)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
E63 E62 E61 E60 E59 E58 E57 E56 E55 E54 E53 E52 E51 E50 E49 E48
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E47 E46 E45 E44 E43 E42 E41 E40 E39 E38 E37 E36 E35 E34 E33 E32
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
LEGEND: R/W = Read/Write; -n = value after reset
Table 11-44. DMA Region Access Enable Registers for Region M (DRAEm/DRAEHm)
Field Descriptions
Bit Field Value Description
31-0 En DMA region access enable for bit n/channel n in region m.
0 Accesses via region m address space to bit n in any DMA channel register are not allowed. Reads return
0 on bit n and writes do not modify the state of bit n. Enabled interrupt bits for bit n do not contribute to the
generation of a transfer completion interrupt for shadow region m.
1 Accesses via region m address space to bit n in any DMA channel register are allowed. Reads return the
value from bit n and writes modify the state of bit n. Enabled interrupt bits for bit n contribute to the
generation of a transfer completion interrupt for shadow region m.
11.4.1.3.2 QDMA Region Access Enable Registers (QRAEm)
The QDMA region access enable register for shadow region m (QRAEm) is programmed to allow or
disallow read/write accesses on a bit-by-bit bases for all QDMA registers in the shadow region m view of
the QDMA registers. This includes all 4-bit QDMA registers.
The QRAEm is shown in Figure 11-61 and described in Table 11-45.
958
Enhanced Direct Memory Access (EDMA) SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
