ELM
www.ti.com
7.4.5.7 ELM Page Definition Register (ELM_PAGE_CTRL)
The ELM Page Definition Register (ELM_PAGE_CTRL) is shown in Figure 7-147 and described in
Table 7-181.
Figure 7-147. ELM Page Definition Register (ELM_PAGE_CTRL)
31 8
Reserved
R-0
7 6 5 4 3 2 1 0
SECTOR_7 SECTOR_6 SECTOR_5 SECTOR_4 SECTOR_3 SECTOR_2 SECTOR_1 SECTOR_0
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 7-181. ELM Page Definition Register (ELM_PAGE_CTRL) Field Descriptions
Bit Field Value Description
31-8 Reserved 0 Reserved.
7 SECTOR_7 0-1 Set to 1 if syndrome polynomial 7 is part of the page in page mode. Must be 0 in continuous
mode.
6 SECTOR_6 0-1 Set to 1 if syndrome polynomial 6 is part of the page in page mode. Must be 0 in continuous
mode.
5 SECTOR_5 0-1 Set to 1 if syndrome polynomial 5 is part of the page in page mode. Must be 0 in continuous
mode.
4 SECTOR_4 0-1 Set to 1 if syndrome polynomial 4 is part of the page in page mode. Must be 0 in continuous
mode.
3 SECTOR_3 0-1 Set to 1 if syndrome polynomial 3 is part of the page in page mode. Must be 0 in continuous
mode.
2 SECTOR_2 0-1 Set to 1 if syndrome polynomial 2 is part of the page in page mode. Must be 0 in continuous
mode.
1 SECTOR_1 0-1 Set to 1 if syndrome polynomial 1 is part of the page in page mode. Must be 0 in continuous
mode.
0 SECTOR_0 0-1 Set to 1 if syndrome polynomial 0 is part of the page in page mode. Must be 0 in continuous
mode.
494
Memory Subsystem SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
