RTC_SS
www.ti.com
20.3.5.24 KICK1R Register (offset = 70h) [reset = 0h]
KICK1R is shown in Figure 20-84 and described in Table 20-87.
The kick registers (KICKnR) are used to enable and disable write protection on the RTC registers. Out of
reset, the RTC registers are write-protected. To disable write protection, correct keys must be written to
the KICKnR registers. The Kick1 register allows writing to unlock the kick1 data and the kicker mechanism
to write to other MMRs. To disable RTC register write protection, the value of 83E7 0B13h must be written
to KICK0R, followed by the value of 95A4 F1E0h written to KICK1R.
Figure 20-84. KICK1R Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
KICK1
W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 20-87. KICK1R Register Field Descriptions
Bit Field Type Reset Description
31-0 KICK1 W 0h
Kick1 data
3658
Timers SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
