LCD Registers
www.ti.com
13.5.1 PID Register (offset = 0h) [reset = 0h]
PID is shown in Figure 13-19 and described in Table 13-14.
Figure 13-19. PID Register
31 30 29 28 27 26 25 24
scheme Reserved func
R-0h R-0h R-0h
23 22 21 20 19 18 17 16
func
R-0h
15 14 13 12 11 10 9 8
rtl major
R-0h R-0h
7 6 5 4 3 2 1 0
custom minor
R-0h R-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 13-14. PID Register Field Descriptions
Bit Field Type Reset Description
31-30 scheme R 0h The scheme of the register used
This field indicates the 3
5 Method
29-28 Reserved R 0h
27-16 func R 0h The function of the module being used
15-11 rtl R 0h The Release number for this IP
10-8 major R 0h
Major Release Number
7-6 custom R 0h
Custom IP
5-0 minor R 0h
Minor Release Number
1130
LCD Controller SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
