McSPI Registers www.ti.com
24.4.1.3 McSPI System Status Register (MCSPI_SYSSTATUS)
The McSPI system status register (MCSPI_SYSSTATUS) provides status information about the module
excluding the interrupt status information. The MCSPI_SYSSTATUS is shown in Figure 24-28 and
described in Table 24-13.
Figure 24-28. McSPI System Status Register (MCSPI_SYSSTATUS)
31 16
Reserved
R-0
15 1 0
Reserved RESETDONE
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 24-13. McSPI System Status Register (MCSPI_SYSSTATUS) Field Descriptions
Bit Field Value Description
31-1 Reserved 0 Reserved for module specific status information. Read returns 0.
0 RESETDONE Internal Reset Monitoring
0 Internal module reset is on-going
1 Reset completed
4036
