Touchscreen Controller Registers
12.5.1.1 REVISION Register (offset = 0h) [reset = 47300001h]
REVISION is shown in Figure 12-5 and described in Table 12-5.
Revision Register
Figure 12-5. REVISION Register
31 30 29 28 27 26 25 24
SCHEME Reserved FUNC
R-1h R-0h R-730h
23 22 21 20 19 18 17 16
FUNC
R-730h
15 14 13 12 11 10 9 8
R_RTL X_MAJOR
R-0h R-0h
7 6 5 4 3 2 1 0
CUSTOM Y_MINOR
R-0h R-1h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-5. REVISION Register Field Descriptions
Bit Field Type Reset Description
31-30 SCHEME R 1h
HL 0.8 scheme
29-28 Reserved R 0h Always read as 0.
Writes have no affect.
27-16 FUNC R 730h
Functional Number
15-11 R_RTL R 0h RTL revision.
Will vary depending on release.
10-8 X_MAJOR R 0h
Major revision.
7-6 CUSTOM R 0h
Custom revision.
5-0 Y_MINOR R 1h
Minor revision
1035
SPRUH73H–October 2011–Revised April 2013 Touchscreen Controller
