Touchscreen Controller Registers
www.ti.com
12.5.1.2 SYSCONFIG Register (offset = 10h) [reset = 0h]
SYSCONFIG is shown in Figure 12-6 and described in Table 12-6.
SysConfig Register
Figure 12-6. SYSCONFIG Register
31 30 29 28 27 26 25 24
Reserved
R/W-0h
23 22 21 20 19 18 17 16
Reserved
R/W-0h
15 14 13 12 11 10 9 8
Reserved
R/W-0h
7 6 5 4 3 2 1 0
Reserved IdleMode Reserved
R/W-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 12-6. SYSCONFIG Register Field Descriptions
Bit Field Type Reset Description
31-4 Reserved R/W 0h
3-2 IdleMode R/W 0h 00 = Force Idle (always acknowledges).
01 = No Idle Mode (never acknowledges).
10 = Smart-Idle Mode.
11 = Smart Idle with Wakeup.
1-0 Reserved R/W 0h
1036
Touchscreen Controller SPRUH73H–October 2011–Revised April 2013
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
