www.ti.com
WATCHDOG
20.4.4.1.16 WDT_WIRQENCLR Register (offset = 60h) [reset = 0h]
WDT_WIRQENCLR is shown in Figure 20-114 and described in Table 20-127.
In the Watchdog Interrupt Enable Clear Register, IRQ enable clear per-event interrupt enable bit vector,
line 0. Write 1 to clear (disable interrupt). Readout equal to corresponding _SET register.
Figure 20-114. WDT_WIRQENCLR Register
31 30 29 28 27 26 25 24
Reserved
R-0h
23 22 21 20 19 18 17 16
Reserved
R-0h
15 14 13 12 11 10 9 8
Reserved
R-0h
7 6 5 4 3 2 1 0
Reserved ENABLE_DLY ENABLE_OVF
R-0h R/W1C-0h R/W1C-0h
LEGEND: R/W = Read/Write; R = Read only; W1toCl = Write 1 to clear bit; -n = value after reset
Table 20-127. WDT_WIRQENCLR Register Field Descriptions
Bit Field Type Reset Description
31-2 Reserved R 0h
1 ENABLE_DLY R/W1C 0h
Enable for delay event
0x0x0(W) = No action
0x0x0(R) = Interrupt disabled (masked)
0x0x1(W) = Disable interrupt.
0x0x1(R) = Interrupt enabled
0 ENABLE_OVF R/W1C 0h
Enable for overflow event
0x0x0(W) = No action
0x0x0(R) = Interrupt disabled (masked)
0x0x1(W) = Disable interrupt.
0x0x1(R) = Interrupt enabled
3697
SPRUH73H–October 2011–Revised April 2013 Timers
Submit Documentation Feedback
Copyright © 2011–2013, Texas Instruments Incorporated
